ULTRA HIGH RESISTANCE VALUES
HERMETICALLY SEALED IN GLASS
Ohm's Law Calculator
| product guide | |
| RX50 RESISTOR | |
ULTRA HIGH RESISTANCE VALUES HERMETICALLY SEALED IN GLASS |
|
| FEATURES | |
| Ultra high values | |
| Impervious to moisture | |
| Resistance tolerances to 5% | |
|
|
| SPECIFICATIONS | |
| Resistance Range: 10 Meg to 100T | |
| Maximum Operating Voltage: 600 | |
| Power Rating: .5 Watt @ 25°C | |
| Operating Temperature: -40°C to +70°C | |
| Resistive Element: Carbon Complex Thick Film | |
| Shelf Life: < 0.5% Resistance Change/Year | |
Ohm's Law Calculator |
|
| TEMPERATURE COEFFICIENT | ||
| RESISTANCE VALUE | PPM/°C | RESISTANCE TOLERANCES (%) |
| 10M - 100M | -1500 | 5 TO 20 |
| 100M - 100T | -2000 | 10 TO 20 |
| HOW TO ORDER | EXAMPLE: 500MEG 5% | |||
| RX50 | 500 | 6 | J | * 5% = J |
| STYLE | RESISTANCE | NO. of ZEROS | *TOLERANCE | 10% = K |
| 20% = M | ||||
| TO ORDER PRODUCTS |
| E mail: microohm@mail.com |
| Call Toll Free: 1-800-845-5167 |
