BT Series
|
Cylindrical Ultra High Ohmic Resistors
Thick Film, Non-Inductive
|
|
|
Ultra High Ohmic, High Voltage & High Frequency Resistors - 700M to 10T
|
|
Micro-Ohm offers the BT series of Ultra High Ohmic values at reasonable prices. An epoxy conformal coat, which has very good humidity protection and good Voltage Coefficient.
|
|
 |
Main Usage: |
 |
BT series resistors are designed to help provide current pulse limiting, detection of trickle current. |
|
| Resistance Range: 700M to 10T |
| Resistance Tolerance: 0.5%, 1%, 2%, 5%, & 10% |
| Temperature: -50°C to +195°C |
Thermal Shock: Mil-Std-202, Method-107, Cond. C,  R, 0.50% max. |
| Load Life: 1,000 hours at rated power R 0.7% max. |
| Insulation Resistance: 10,000MΩ min. |
| Cap & Lead Material: Tinned Cap, tinned copper wire |
| Resistive Marterial: Thick Film |
|
|
|
|
| Dimensions |
 |
|
|
 |
|
|
|
Model
No. |
Wattage at 25°C |
Max. Continuous
Oper. Volt [kV]
|
Impulse
Voltage [kv]
1.2x50µsec |
Resistance
( ) |
| Min. |
Max. |
| BT50 |
0.5 |
2.0 |
4.0 |
700M |
50G |
| BT70 |
0.7 |
5.0 |
10.0 |
700M |
1T |
| BT1 |
1.0 |
5.0 |
10.0 |
700M |
1T |
| BT1.5 |
1.5 |
10.0 |
20.0 |
1G |
10T |
| BT2 |
2.0 |
12.0 |
24.0 |
1G |
10T |
|
|
|
|
|
|
Model
No. |
Dimensions in milimeters |
| A |
B |
C |
| BT50 |
15.0 ±1.5 |
5.0 ±1.5 |
0.8 |
| BT70 |
25.4 ±1.5 |
5.0 ±1.5 |
0.8 |
| BT1 |
24.0 ±1.5 |
8.0 ±1.0 |
1.0 |
| BT1.5 |
39.0 ±1.5 |
8.0 ±1.0 |
1.0 |
| BT2 |
52.0 ±1.5 |
8.0 ±1.0 |
1.0 |
|
Temperature
Coefficient
|
R-Range
|
1GΩ to 9GΩ
|
10GΩ to 300GΩ
|
400GΩ to 1TΩ
|
1.1TΩ to 10TΩ
|
|
R taken @ 25°C and 70°C
|
|
[ppm]/°C
|
200
|
300
|
1000
|
1500
|
|
|
Voltage
Coefficient
|
R-Range
|
10GΩ to 19GΩ
|
20GΩ to 100GΩ
|
200GΩ to 1TΩ
|
10TΩ
|
|
Measured at 100vdc and 1000vdc
|
|
VCR
|
0.002%/V
|
0.007%/V
|
0.01%/V
|
0.05%/V
|
|
|
Resistance Tolerance (%)
|
R-Range
|
1GΩ
|
2GΩ to 10GΩ
|
20GΩ to 100GΩ
|
200GΩ to 1TΩ
|
10TΩ |
Measured at 1000vdc standard
|
|
Std.
|
±1%(F)
|
±2%(G).
|
±5%(J)
|
±10%(K) |
±20% |
|
Custom
|
±0.5%
|
±1%
|
±2%
|
±5%
|
±10%
|
|
|
ORDERING INFORMATION
|
|
|
|
| Example: 2W 1Gig 5% |
|
|
|
|
BT2
|
1G
|
J
|
|
Type
|
Resistance
|
Tolerance
|
|
|
F = 1%
G = 2%
J = 5%
K = 10%
|
|
|
